Praxis CS Zane DM M30 120mm
Praxis CS Zane DM M30 120mm
Praxis CS Zane DM M30 120mm
Praxis CS Zane DM M30 120mm
Praxis CS Zane DM M30 120mm

Praxis CS Zane DM M30

From:  £170.00
Lightweight forged M30 aluminium cranks perfect for Youth riders or those wanting shorter cranks. Specification Specification     Crank/Use: ZANE: Youth MTN Crank. Buy This If: You are lo...Learn more
Size: 120mm
Product Code: PR-Z120
£170.00
Minus
1
Plus
£170.00
In stock with supplier, dispatched in 5 days

Click & Collect

Select Click & Collect at checkout and pick up your order at a convenient location

Walton

Special order
Ready in 5 days
Map Marker icon Auckland House, New Zealand Ave, Walton-on-Thames KT12 1PL
Email icon walton@99bikes.co.uk
Phone number icon 01932 901437
£170.00 + Add to cart

Lightweight forged M30 aluminium cranks perfect for Youth riders or those wanting shorter cranks.

Specification

Specification

Crank/Use: ZANE: Youth MTN Crank.
Buy This If: You are looking for a lightweight alloy youth crank arm set in shorter lengths.
Material Forged Alloy Arms | Alloy M30 spindle (30mm/28mm).
Weight 522g : ZANE 130mm Arm set (Ref. Length).
Chainring Any brand 3-Bolt Direct Mount ring can be used for SRAM & SHIMANO Compatibility The chainring type and offset determines compatibility with any given MTN bike drivetrain.
PRAXIS DM1X RINGS.
MTN Chainline 0mm Offset Ring = 55mm CL.
3mm Offset Ring = 52mm CL "Boost".
6mm Offset Ring = 49mm CL "Non-Boost".
Q-Factor 172mm.
Main bolt 8mm Alloy M30-Main crank bolt for Install/Self-Extract.
B.B. This crank requires our Praxis M30 BB | 30mm Drive Bearing / 28mm NonDrive Bearing M30 BOTTOM BRACKET (REQUIRED) | BSA / BB90-92 / T47 E.B / BB30 / PF30.
