bottom bracket
|
SRAM DUB PF 92 MTB Wide, shell 41x92mm
|
|
brakes
|
Front - SRAM Motive Silver 4-Piston Disc Rear - SRAM Motive Silver 4-Piston Disc
|
|
cassette
|
SRAM X0 Eagle XS 1295 Transmission 10-52
|
|
crankset
|
SRAM X0 Eagle Transmission, Spindle Power Meter, DUB, 55mm CL, 34T
|
|
fork
|
RockShox SID Ultimate Flight Attendant, Electronically controlled Suspension, FA Race Day damper 3 Modes, 15x110mm Maxle Stealth, 44mm offset /Tapered steerer, Lockout, Reb. Adj., 120mm travel
|
|
frame
|
Spark RC Carbon HMF, Integrated Suspension Technology, Flex Pivot, Adjustable head angle, Syncros Cable Integration System, BB92, UDH Interface, 12x148mm with 55mm Chainline
|
|
grips
|
Syncros Performance XC lock-on grips
|
|
handlebars
|
Syncros Fraser iC SL XC Carbon, -12° rise, back sweep 8°, 740mm
|
|
headset
|
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
|
|
material
|
Aluminum
|
|
rear derailleur
|
SRAM X0 Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
|
|
rear shock
|
RockShox SIDLuxe Ultimate Flight Attendant Custom, Electronically controlled Suspension, 3 Modes Lockout-Pedal-Descend, Solo Air, Reb. Adj./ Lockout, Bearing Hardware, Travel 120mm, T165X45mm
|
|
rotor
|
Front - SRAM HS2 CL 180mm Rear - SRAM HS2 CL 160mm
|
|
seatpost
|
Syncros Duncan Dropper 1.5XC, 31.6mm, all sizes 100mm
|
|
shifters
|
SRAM AXS Rocker Pod Controller
|
|
tyres
|
Front - Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO Rear - Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
|
|
wheelset
|
Syncros Silverton 1.0-30 CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready Carbon rim 28H, Syncros Hubs, XD Driver, Syncros SL Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
|
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
