bottom bracket
|
Shimano BB-RS500, BSA 68
|
|
brakes
|
Shimano 105 R7170 hydraulic disc, 160/160mm CL700 rotors
|
|
brake levers
|
Shimano 105 Di2 R7170 hydraulic disc
|
|
cassette
|
Shimano 105 R7100, 11-34, 12-speed
|
|
chain
|
Shimano 105, 12-speed
|
|
crankset
|
Shimano 105 7100, 50/34: 165mm (44-50cm), 170mm (52-56cm), 172.5 (58-61cm)
|
|
fork
|
SuperSix EVO Carbon, Gen 5, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm)
|
|
frame
|
SuperSix EVO Carbon, Gen 5, integrated cable routing, 12x142 thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, UDH
|
|
front derailleur
|
Shimano 105 Di2 R7170
|
|
grips
|
Cannondale Bar Tape, 3.5mm
|
|
handlebars
|
Vision Trimax Aero: 400mm (44-56), 420mm (58-61)
|
|
headset
|
Integrated, 1-1/8" - 1-1/4"
|
|
hubs
|
Vision, centerlock, (F) 12x100mm, (R) Vision, 12x142mm
|
|
rear derailleur
|
Shimano 105 Di2 R7150, 12-speed
|
|
rims
|
Vision SC45 I23, carbon, 23mm inner width, 45mm depth
|
|
saddle
|
Fizik Vento Antares R7, 140mm
|
|
seatpost
|
Cannondale C1 Aero 40 Carbon V2, 365mm, 0mm offset (44-54cm), 15mm offset (56-61cm)
|
|
shifters
|
Shimano 105 Di2 R7170, wireless, 2x12-speed
|
|
spokes
|
2:1 aero bladed direct pull
|
|
stem
|
Cannondale C1 Conceal, Alloy, 31.8, -6°: 80mm (44cm), 90mm (48-52cm), 100mm (54-56cm), 110mm (58-61cm)
|
|
tyres
|
Schwalbe One TLR, 700x28c, tubeless ready
|
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
