Frame - Alloy S-XL=29" / 6061 Alloy custom butted tubing, Top extraction battery, UDH Interface / 12x148mm with 52mm Chainline
Fork - SR Suntour XCM34 LO Coil / Tapered / 15x110 bolt Axle / Lock Out / 100mm Travel
Shift Levers - Shimano CUES RD-U6000GS 10 Speed
Number Of Gears - 10
Brake Front - Shimano BR-MT200 Disc
Brake Rear - Shimano BR-MT200 Disc
Brake Disc Front - Shimano SM-RT30 CL 180mm
Brake Disc Rear - Shimano SM-RT30 CL 160mm
Rim Front - Syncros X18 Disc
Rim Rear - Syncros X18 Disc
Tyre Front - Schwalbe Big Apple Performance, 60-622
Tyre Rear - Schwalbe Big Apple Performance, 60-622
Hub Front - Shimano HBTC50015BB CL / 15x110mm
Hub Rear - Shimano FHTC500HMBB / 148x12mm
Spokes - Black Spokes
Handlebar - Syncros UC3.0 680mm / Rise 12mm / Backsweep 15°
Stem - Syncros UC 3.0 adjustable with front Light mount
Stem Length - 90
Headset - Acros / 1.5"- 1.5", semi integ. OD 50/61mm / ID 44/55mm
Saddle - Syncros Capilano
Seat Post - Syncros 3.0 / 31.6mm / 350mm
Crankset - FSA CK-220 170mm
Drive - Shimano LG500
Sprocket - Shimano CS-LG40010 11-48 T
Pedals - Marwi SP-828
Front Light - Lezyne Hecto E65
Rear Light - Lezyne Rack Light
Rack - Racktime carrier SnapIt 2.0 27KG
Rack Load Capacity - 27
Mudguards - Curana alloy profile
Stand - Ursus
Motor - Bosch Performance CX, EU: 25kmh
Battery - PowerTube 600Wh
Battery Capacity - 600
Display - Bosch Purion 200
Charger - 2A Charger
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
