Highlights:
- Lightweight CF3 carbon frame with 2.4" tyre clearance
- Progressive geometry with Agilometer sizing for confident handling
- RockShox Judy Gold 120mm fork with remote lockout
- Shimano 12-speed drivetrain
- Dropper seatpost with remote lever
The low weight of a carbon frame for the uphill, paired with trail-hardtail swagger, 120mm fork, aggressive tyres and a dropper post mean you've got a recipe for fun.
Mountain biking is one of the most varied cycling disciplines and probably the most demanding when it comes to equipment. While full suspension bikes offer amazing riding characteristics, the classic hardtail remains one of the purest tools for the job.
Specification
Frame
- CF3 III - carbon; Boost axle standard, BSA BB standard, Max. tyre size 29" x 2.4"
Fork
- RockShox Judy Gold; Air; 120mm travel; Tapered; Remote lockout; 51 mm fork offset
Gears
- 12
Shifters
- Shimano Deore M6100 and JD-FL dropout lever
Rear Derailleur
- Shimano XT; SGS
Bottom Bracket
- Shimano BB-MT-501; 24mm
Chain
- KMC X12
Chainset
- Shimano Deore MT512; 32 tooth chainset with 170mm (S), 175mm M and above
Cassette
- Shimano Deore M6100; 10-51 teeth; 12 speed
Brake Lever
- Shimano SLX
Front Brake
- Shimano SLX M7100; 2 piston hydraulic disc brake with Shimano RT-54 180mm rotor
Rear Brake
- Shimano SLX M7100; 2 piston hydraulic disc brake with Shimano RT-54 160mm rotor
Grip
- Merida Expert EC
Handlebar
- Merida Expert CC; aluminium; 760mm wide; flat
Stem
- Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise; length: 60mm (S/M/L); 70mm (XL); incl. Merida Smart Mount - Garmin Carrier + Garmin insert *2 + GoPro/Light Mount
Head Set
- Acros ICR Merida integrated neck; Upper and lower IPS sealing
Saddle
- Merida Expert SL; V-mount; incl. Merida minitool
Seat Post
- Merida Team TR SL; 30.9mm diameter; in-line; S/M: 150mm seat post travel (S/M), 170mm seat post travel (L/XL/XXL)
Rims
- Merida Expert CC II; 25mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included)
Spokes
- Double Butted Black stainless
Front Hub
- Shimano HB-TC500-B; 100 x 15mm; 32 Spokes; Centerlock
Rear Hub
- Shimano TC500-MS-B; 148 x 12mm; 32 Spokes; Centerlock with Merida Expert TR axle; including removeable lever, 6/4mm allen key
Front Tyre
- Maxxis Rekon; 29 x 2.4" WT; tubeless ready; 3C EXO
Rear Tyre
- Maxxis Rekon Race; 29 x 2.4" WT; tubeless ready; 3C MaxxTerra EXO
Colour
- Grey/Silver/Black
Season
- 2025
