battery
|
Bosch 400 Wh Internal
|
|
brakes
|
Magura MT7 with HC3 Lever, 4 Piston Hydraulic Disc, E-Specific Pads, 203mm MDR RotorMagura MT7 with HC3 Lever, 4 Piston Hydraulic Disc, E-Specific Pads, 203mm MDR Rotor
|
|
brake levers
|
Magura MT7 with HC3 Lever
|
|
cassette
|
SRAM CS-XS-1275 T-Type, 10-52T
|
|
chain
|
SRAM GX T-Type
|
|
crankset
|
e*thirteen e*spec Plus Carbon, 160mm Length, 34T
|
|
display
|
Bosch BRC3100 Systems Controller
|
|
frame
|
All New Series 4 Alloy Lightweight E, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle
|
|
grips
|
Marin Grizzly Lock-On
|
|
handlebars
|
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
|
|
headset
|
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
|
|
hubs
|
Front: Formula DCL-3482, 4 Sealed Bearings, 148x12, XD Driver, 6-Bolt, 32H Rear: Formula DC-711, 110x15, 6-Bolt, 32H
|
|
motor
|
Bosch Performance Line SX, 600W, 55Nm
|
|
rear derailleur
|
SRAM GX AXS T-Type
|
|
rear shock
|
Fox Float X, Performance Elite, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x55mm, 25xM8 Upper Mount, No Lower DU or Hardware
|
|
rims
|
Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Welded Joint, Disc Specific, Tubeless Compatible
|
|
seatpost
|
TranzX, YSI08 FL, 1x Remote,, 5mm Micro Adjust up to 25mm, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 34.9mm
|
|
shifters
|
SRAM AXS Pod
|
|
tyres
|
Front: Maxxis Minion DHF, 29x2.5" MAXXGRIP, Tubeless ready, EXO+, Rear: Maxxis Forecaster 29x2.4", Tubeless Ready MAXX TERRA EXO+
|
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
