battery
|
Bosch 400Wh Internal
|
|
brakes
|
TRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm RotorTRP Slate EVO, 4-Piston Hydraulic Disc, Resin Pads, 203mm Rotor
|
|
brake levers
|
TRP Slate EVO, I-Spec EV Compatible
|
|
cassette
|
Shimano CS-LG300-10, 11-48T
|
|
chain
|
Shimano LG500
|
|
crankset
|
e*thirteen e*spec Plus, 160mm Length, 34T
|
|
display
|
Bosch BRC3100 Systems Controller
|
|
frame
|
All New Series 4 Alloy Lightweight E, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle
|
|
grips
|
Marin Grizzly Lock-On
|
|
handlebars
|
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
|
|
headset
|
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
|
|
hubs
|
Front: Shimano, 110x10 Thru Axle, 32H, Centerlock Rear: Shimano FHTC500, 148x12 Thru Axle, Mircospline, 32H, Centerlock
|
|
motor
|
Bosch Performance Line SX, 600W, 55Nm
|
|
rear derailleur
|
Shimano CUES RD-U6000 GS, 10-Speed
|
|
rear shock
|
Marzocchi Bomber Air Shock, ALL NEW for 2025, Custom Tune, 210x55mm, 25xM8 Upper Mount, No Lower DU or Hardware
|
|
rims
|
Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible
|
|
seatpost
|
TranzX, YSI34 QL, Plastic 1x Remote, Size S 150mm Travel, Size M and L 170mm Travel, Size XL 200mm Travel, 34.9mm
|
|
shifters
|
Shimano CUES SL-U6000-10R, 10-Speed
|
|
tyres
|
Front: Maxxis Minion DHF, 29x2.5" MAXXGRIP, Tubeless ready, EXO+, Rear: Maxxis Forecaster 29x2.4", Tubeless Ready MAXX TERRA EXO+
|
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
