battery
|
N/A
|
|
brakes
|
Tektro Slate EVO, 4-Piston Hydraulic Disc Brake, Resin Pads, 203mm RotorTektro Slate EVO, 4-Piston Hydraulic Disc Brake, Resin Pads, 180mm Rotor
|
|
brake levers
|
Tektro Slate EVO Hydraulic Lever, I-Spec EV Compatible
|
|
cassette
|
Shimano, Deore M6100 12-Speed, 10-51T
|
|
chain
|
KMC X-12 Silver and Black
|
|
crankset
|
FSA Comet Heavy Duty, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
|
|
display
|
N/A
|
|
fork
|
Fox 36 Rhythm, 170mm Travel, 29", Grip Damper, 110x10 Kabolt, 44mm Offset
|
|
frame
|
All New Series 4 6061 Aluminum Frame, 29” Wheels, 160mm Travel MultiTrac LT Suspension Platform, Integrated Downtube Storage, Adjustable Headset & CS Length/BB Height, Full Internal Cable Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs
|
|
grips
|
Marin Grizzly Lock-On
|
|
handlebars
|
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
|
|
headset
|
FSA Custom Headset, Adjustable HTA Design
|
|
hubs
|
Front: Shimano HF-MT410B, 110x15mm, Centerlock Rear: Shimano HB-MT410B, 148x12mm, Centerlock, Microspline Freehub Body
|
|
motor
|
N/A
|
|
rear derailleur
|
Shimano Deore, 12-Speed, SGS
|
|
rear shock
|
Fox Float Performance, 205x65, 30xM8 Lower Hardware, Custom Tune
|
|
rims
|
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
|
|
seatpost
|
TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm
|
|
shifters
|
Shimano Deore, 12-Speed, SL-6100-IR
|
|
tyres
|
Vee Tire Flow Snap, 29x2.6" Front 27.5x2.5" Rear, Top 40 Compound, Enduro Core, 72 TPI, Tubeless Compatible
|
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
