Frame: Spark Alloy SL 6011 Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork: RockShox Judy Silver TK Solo Air 15x110mm QR axle / 42mm offset / Tapered Steerer 2-Modes / Reb. Adj. / Lockout / 130mm travel
Rear Shock: X-Fusion NUDE 5 RLX Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj. Travel 120-80-Lockout / T165X45mm
Remote System: SCOTT TwinLoc 2 Technology Suspension & Dropper Remote 3 Suspension modes
Rear Derailleur: Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
Shifters: Shimano Deore SL-M6100-R / Rapidfire Plus
Crankset: Praxis Cadet M24 55mm CL / 32T
BB-Set: Praxis M24 BB92 / shell 41x92mm
Chain: KMC X12
Cassette: Shimano Deore CS-M6100-12 / 10-51 T
Brakes: Shimano MT501 Disc
Rotor: Shimano SM-RT54 CL / F&R 180mm
Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B. mini Rise / back sweep 8° / 760mm Syncros Performance XC lock-on grips
H'stem: Syncros DC 3.0 Syncros Cable Integration System 0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost: Syncros Duncan Dropper Post 2.5 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
Seat: Syncros Tofino 2.5 Regular
Headset: Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Hub (Front): Shimano HB-MT410-B CL / 15x110mm
Hub (Rear): Shimano FH-MT410-B CL / 12x148mm / Micro Spline
Spokes: Stainless Black 15G / 1.8mm
Rims: Syncros X-30SE / 32H / 30mm
Front Tire: Schwalbe Wicked Will / 29x2.4" Performance / TLR / Foldable / Addix
Rear Tire: Schwalbe Wicked Will 29x2.4" Performance / TLR / Foldable / Addix
Approx weights in KG: 14.95 (with tubes)
Approx weights in LBS: 32.96 (with tubes)
Max. System Weight: 128kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
