Frame: Scale Carbon HMF Adjustable head angle / Syncros Cable Integration System Advanced Shock & Standing Damping System BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork: FOX 32 SC Float Performance Air Grip 3-Modes / 15x110mm QR axle / 44mm offset / tapered steerer Lockout / Reb. Adj. / 100mm travel
Remote System: SCOTT RideLoc 2 Technology 3 Suspension modes
Rear Derailleur: SRAM GX Eagle 12 Speed
Shifters: SRAM NX Eagle Trigger
Crankset: SRAM GX Eagle DUB 55mm CL / 32T BB-Set SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain: SRAM CN NX Eagle
Cassette: SRAM XG1275 / 10-52 T
Brakes: Shimano Deore M6100 Disc Brake
Rotor: Shimano SM-RT64 CL / 180/F and 160/R
Handlebar: Syncros Fraser 2.0 XC Alloy 6061 D.B. Flat Bar / 8° / 740mm Syncros Performance XC lock-on grips
H'stem: Syncros XC 2.0 Syncros Cable Integration System -12° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost: Syncros Duncan 2.0 31.6x400mm
Seat: Syncros Belcarra Regular 2.0 CrMo rails
Headset: Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
Hub (Front): Formula CL-811 / 15x110mm
Hub (Rear): Formula CL-14811 / 12x148mm / XD Driver
Spokes: Stainless Black 15G / 1.8mm
Rims: Syncros X-30SE / 32H / 30mm Tubeless ready
Front Tire: Schwalbe Racing Ray 29x2.35" Performance Folding / TLE Tubeless ready / Addix
Rear Tire: Schwalbe Racing Ralph 29x2.35" Performance Folding / TLE Tubeless ready / Addix
Approx weights in KG: 11.3 (with tubes)
Approx weights in LBS: 24.91 (with tubes)
Max. System Weight: 128kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
* Any weights shown are based on production painted frames as pictured. Actual weights will vary with colourway, frame size and component variation. Specifications are supplied by the manufacturer and are subject to change without notice.
